CO2 Refrigeration

AIST CO2 Module Unit

Name: AIST CO2 Module Unit
Brand: MOON-TECH

NH3/CO2 cascade modular unit, skid-mounted with container housing — no refrigeration control room required.

Get a Quote Browse Equipment

Overview

AIST CO2 Module Unit

The AIST series carbon dioxide module unit is a new type of high-efficiency refrigeration equipment built on MOON-TECH’s promotion and application experience of CO2 refrigeration technology and related refrigeration systems. The unit uses a number of innovative technologies, such as the CO2 screw compressor, no-liquid-storage micro-pressure-drop small-charge condenser, combined rotary gas-liquid separation and micro-gravity liquid level control technology, and automatic intelligent control technology. The whole machine is skid-mounted, without a refrigeration control room — safe, energy-saving and environmentally protected. At present, the unit has been widely used at home and abroad.

Specification

Published parameters

AIST CO2 Module Unit — as published by MOON-TECH
Refrigerant	NH3 / CO2 (cascade)
Nominal working condition	−38 / +40 °C
Unit cooling capacity	271 – 526 kW
CO2 pump flow	6 – 10 m³/h
NH3 filling amount	110 – 220 kg
CO2 filling amount	2,700 – 5,200 kg

Features

What the unit does

Uses NH3 and CO2 — safe, environmentally friendly and energy-saving refrigerants with excellent environmental protection performance
Modular design with container housing: no machine room required, easy operation and maintenance
Frequency conversion start and run — no impulse current, significant energy-saving advantage
High degree of system automation reduces manual commissioning time and operating cost
Integrated active defense system with real-time monitoring, alarm and spray device — high safety
Higher cooling capacity per unit volume of CO2 and higher heat transfer efficiency

Applications

Where it runs

The AIST series is widely used in cryogenic refrigeration in food processing, low-temperature process cooling in the pharmaceutical and chemical industry, process cooling in dangerous operating areas, and artificial-environment applications.
